LXC11P-1468C Dual Layer Leanloader

For small-batch, high-mix metal machining, Leantec’s modular mobile robotic flexible unit enables automated and adaptive production. With simple commissioning and rapid deployment, it provides the perfect solution for the challenges of diverse, low-volume machining operations.

*Sales Regions: Taiwan, Overseas

Model	LXC11P-1468C
Robot Model	LA1468-10
Robot Max Payload (kg)	10
Robot Max Arm Reach (mm)	1468
Repeatability (mm)	±0.05
IP Rating	IP54
Product Dimension (mm)	2400 x 850
Tray Dimension (mm)	800 x 600
Tray Max Load (kg)	80
Suitable Workpiece	Small to medium size workpiece with angle positioning feature
Max Workpiece Height (mm)	135
End Effector	Optional

Product Manual

【Disclaimer】
By clicking the product manual link, you will be leaving this website. The external link is provided solely for your convenience and information.
Please note that the external website is maintained by a third party, and this site is not responsible for any loss or damage incurred from its use.

Rapid Deployment

Flexible & mobile design with lockable casters & fixed brackets, robot can be easily moved and positioned according to production needs.

Rapid Communication

Easy integration with Syntec’s machine tool controllers via single network cable. For third-party systems, IO plug and play connectors to enable signal handshake and communication.

Rapid Commissioning

Commissioning only requires communication signal testing and pick & place point teaching, minimizing on-site debugging time and quick deployment to production.

Rapid Line Change

Quick workstations relocation & products changed according to production plan, swift setup and simple adjustments to fulfill line changeover requirements.

Continuous Production

Add new workpieces for processing without stopping robot and machine, ensuring continuous production to eliminate production downtime.

High mix, low volume production has become the standard in smart factories, with industrial robot playing a crucial role in the manufacturing process. However, conventional industrial robot often present challenges such as large footprints, difficult line change, and long setup times, which can discourage factory operators.

To address these issues, Leantec offers machine tools loading and unloading mobile cart solution. Leanloader, equipped with robotic arms, mobile carts, and tray storage modules, is ideal for small-batch, diverse metal processing applications. The robotic arm and cart move wherever needed, bringing flexibility and agility to your factory.
